More Standard Features

• 16 MB SD RAM; 8 MB non-volatile Flash memory
• Automatic media/ribbon sensing capability
• Improved head test for element out
• Auto calibration
• Clear media side door for ease of supplies monitoring
• 300 unique darkness settings
• RS-232, Parallel ports
• USB 2.0 port
• Internal ZebraNet 10/100 PrintServer
• ZPL or ZPL II Programming Language
• XML enabled printing
• Mirror feature allows user-defined printer configurations to be retrieved from the network
• Create and design customizable printer LCD menus
• Large (240W x 128H pixel), graphical, multilingual, backlit LCD display
• Transmissive and reflective media sensors
• Multi-level Element Energy Equalizer (E3) for superior print quality
• Unicode™ - Compliant
• Intelligent printhead

Printer Specifications

Resolution: 203 dpi (8 dots/mm)
300 dpi (12 dots/mm)
600 dpi (23.5 dots/mm)
Memory

• 16 MB SDRAM
• 8 MB Flash

Print width: 4.0" (102mm)
Print length: 150" (3810 mm) maximum with 110Xi4 203 dpi using continuous media
Print speed: Up to 14" per second
Media sensors: Reflective, Transmissive

Media Characteristics

Maximum label and liner width: 4.5" (114mm)
Minimum label and liner width: .79" (20mm)
Maximum label and liner length: 39" (991mm) non-continuous to 150"
(3810mm) continuous media
Maximum roll diameter: 8.0" (203mm)
Core diameter: 3" (76mm)
Media thickness: .003" (.076mm) to .012" (.305mm)
Media types: black mark, continuous, roll-fed, die-cut, fanfold

Ribbon Characteristics

Outside diameter: 3.2" (81.3mm)
Standard length: 1476' (450m) or 984' (300m)
Ratio: 2:1 or 3:1 media roll to ribbon ratios
Ribbon width: .79" (20mm) to 4.33" (110mm)
Ribbon setup: Ribbon wound ink side out
ID Core: 1.0" (25.4 mm)

Operating Characteristics

Operating temperature TT: Operating temperature: 40° F (5° C) to 105° F (40° C)
Thermal transfer DT: Operating temperature: 32° F (0° C) to 105° F (40° C)
Direct thermal Storage temperatures: -40° F (-40° C) to 140° F (60° C)
Operating humidity: 20% to 85% non-condensing relative humidity
Storage humidity: 5% to 85% non-condensing relative humidity
Electrical: Universal power supply with power factor connection 90-264 VAC; 48 - 62 Hz
Agency approvals

• BSMI
• cTUVus
• CCC
• CE
• C-Tick
• EN55022 Class B
• EN55024
• EN61000-3-2,3
• FCC Class B
• GOST-R
• ICES-003 Class B
• IEC 60950-1 / EN60950
• KCC
• NOM
• S Mark
• STB
• UkrSEPRO
• VCCI
• ZIK

Physical Characteristics

Width: 10.31" (261.9mm)
Height: 15.5" (393.7 mm)
Depth: 20.38" (517.5 mm)
Weight: 50 lbs (22.7 kg)

Related Products

Options

• ZebraNet Wireless Plus Print Server
• ZebraNet Internal Wireless Plus (Discontinued)
• Internal IPv6 Print Server
• IBM Twinax interface
• IBM Coax interface
• Rewind with peel
• Cutter
• Bi-fold media door with clear panel
• Media supply spindle for 40 mm cores
• 64MB Flash Memory with ZPL II and XML (with element out detection)
• 64MB Flash Memory with ZPL II and XML (without element out detection)
• 16MB SDRAM (Printhead element out detection) with ZPL II and XML
• Scalable and international fonts
• Applicator interface
• ZebraDesigner
• ZebraDesigner Pro
• ZebraDesigner for XML
• ZebraNet Bridge
• Enterprise Connector
• ZebraNet b/g Print Server

Communication and Interface Capabilities

• USB 2.0 port (12 Mbits per second)
• RS-232C/422/485 multi-drop (optional adaptor)
• High-speed, bi-directional, IEEE 1284 parallel interface
• ZebraNet Wireless Plus Print Server
• ZebraNet 10/100 Print Server
• IBM Twinax interface
• IBM Coax interface
• Applicator interface
• IPV6 Print Server
• ZebraNet b/g Print Server

Programming Languages

Core programming languages: ZPL II, ZPL, XML

Bar Codes/Symbologies

Linear Code 11
Code 39
Code 93
Code 128 with subsets A/B/C and UCC case codes
UPC-A
UPC-E
EAN-8
EAN-13
UPC and EAN 2 or 5 digit extensions
Plessey
Postnet
Standard 2-of-5
Industrial 2-of-5
Interleaved 2-of-5
Logmars
MSI
Planet Code
Codabar
2-dimensional Codablock
PDF417
Code 49
Data Matrix
MaxiCode
QR Code
TLC 39
MicroPDF
Aztec
RSS / GS1 DataBar family (12 barcodes)
Fonts and Graphics

• Bitmap fonts A through H and GS symbols are expandable up to 10 times, height and width independent
• Smooth scalable font (CG Triumvirate™ Bold Condensed) is expandable dot-by-dot, height and width independent
• IBM^® Code Page 850 International Characters
